H7125N
3-way globe valve, PN16 flange, DN 125, kvs 220 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
H712N
3-way globe valve, PN16 flange, DN 15, kvs 1 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
H712R
3-way globe valve, PN6 flange, DN 15, kvs 1 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
H713N
3-way globe valve, PN16 flange, DN 15, kvs 1,6 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
H713R
3-way globe valve, PN6 flange, DN 15, kvs 1,6 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
H714N
3-way globe valve, PN16 flange, DN 15, kvs 2,5 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
H714R
3-way globe valve, PN6 flange, DN 15, kvs 2,5 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
H7150N
3-way globe valve, PN16 flange, DN 150, kvs 320 Housing and seat gray cast iron GG25 Ball stainless steel Stem/bypass-seat stainless steel Seal EPDM O-ring Temperature of medium max. 120°C Characteristic A-AB equal percentage Characteristic B-AB linear Leakage rate A-AB max. 0.05% of kvs Leakage rate B-AB 1% of kvs Design mixing valve
R2015-1P6-S1
2-way characterised control valve, ps 1600 kPa Internal thread 1/2", DN 15, kvs 1.6 m³/h Housing brass body nickel-plated Closing element stainless steel Stem stainless steel Stem seal O-ring EPDM Characterising disk TEFZEL Valve seat PTFE, O-ring EPDM Medium temperature -10...120°C Equal percentage characteristic curve (VDI/VDE 2178), optimised in the...
R2015-1-S1
2-way characterised control valve, ps 1600 kPa Internal thread 1/2", DN 15, kvs 1 m³/h Housing brass body nickel-plated Closing element stainless steel Stem stainless steel Stem seal O-ring EPDM Characterising disk TEFZEL Valve seat PTFE, O-ring EPDM Medium temperature -10...120°C Equal percentage characteristic curve (VDI/VDE 2178), optimised in the...
